ESPHome 2026.11.0b6
|
#include <usb_host.h>
Public Member Functions | |
| USBClient (uint16_t vid, uint16_t pid) | |
| void | setup () override |
| void | loop () override |
| float | get_setup_priority () const override |
| void | on_opened (uint8_t addr) |
| void | on_removed (usb_device_handle_t handle) |
| bool | transfer_in (uint8_t ep_address, const transfer_cb_t &callback, uint16_t length) |
| Performs a transfer input operation. | |
| bool | transfer_out (uint8_t ep_address, const transfer_cb_t &callback, const uint8_t *data, uint16_t length) |
| Performs an output transfer operation. | |
| void | dump_config () override |
| void | release_trq (TransferRequest *trq) |
| trq_bitmask_t | get_trq_in_use () const |
| bool | control_transfer (uint8_t type, uint8_t request, uint16_t value, uint16_t index, const transfer_cb_t &callback, const std::vector< uint8_t > &data={}) |
| void | set_manufacturer_filter (const char16_t *manufacturer) |
| void | set_product_filter (const char16_t *product) |
| bool | is_connected () const |
| Whether a device has been opened and its setup by the subclass has finished. | |
| bool | get_device_info (UsbDeviceInfo &info) const |
| Copy the connected device's identity out of the cached USB descriptors. | |
| template<typename F > | |
| void | add_on_connection_callback (F &&callback) |
| Register a callback for the device this client claims being connected (true) or removed (false). | |
Public Member Functions inherited from esphome::Component | |
| float | get_actual_setup_priority () const |
| void | set_setup_priority (float priority) |
| void | call () |
| virtual void | on_shutdown () |
| virtual void | on_safe_shutdown () |
| virtual bool | teardown () |
| Called during teardown to allow component to gracefully finish operations. | |
| virtual void | on_powerdown () |
| Called last before a reboot or deep sleep to power down hardware. | |
| uint8_t | get_component_state () const |
| void | reset_to_construction_state () |
| Reset this component back to the construction state to allow setup to run again. | |
| bool | is_in_loop_state () const |
| Check if this component has completed setup and is in the loop state. | |
| bool | is_idle () const |
| Check if this component is idle. | |
| void | mark_failed () |
| Mark this component as failed. | |
| void | mark_failed (const LogString *message) |
| bool ESPHOME_ALWAYS_INLINE | setup_check (bool ok) |
Marks the component failed with message (default "Communication failed") unless ok; returns ok. | |
| bool ESPHOME_ALWAYS_INLINE | setup_check (bool ok, const LogString *message) |
| void | disable_loop () |
| Disable this component's loop. | |
| void | enable_loop () |
| Enable this component's loop. | |
| void | enable_loop_soon_any_context () |
| Thread and ISR-safe version of enable_loop() that can be called from any context. | |
| bool | is_failed () const |
| bool | is_ready () const |
| virtual bool | can_proceed () |
| bool | status_has_warning () const |
| bool | status_has_error () const |
| void | status_set_warning () |
| void | status_set_warning (const char *message) |
| void | status_set_warning (const LogString *message) |
| bool | status_comm_result (bool ok) |
Clears the warning when ok, else sets it with message (default "Communication failed"); returns ok. | |
| bool | status_comm_result (bool ok, const LogString *message) |
| void | status_set_error () |
| void | status_set_error (const LogString *message) |
| void | status_clear_warning () |
| void | status_clear_error () |
| ESPDEPRECATED ("Use status_momentary_warning() without a name. Removed in 2027.5.0", "2026.11.0") void status_momentary_warning(const char *name | |
| void | status_momentary_warning (uint32_t length=5000) |
Set warning status flag and clear it after length ms. | |
| void | status_momentary_warning (const LogString *message, uint32_t length=5000) |
| ESPDEPRECATED ("Use status_momentary_error() without a name. Removed in 2027.5.0", "2026.11.0") void status_momentary_error(const char *name | |
| void | status_momentary_error (uint32_t length=5000) |
Set error status flag and clear it after length ms. | |
| void | status_momentary_error (const LogString *message, uint32_t length=5000) |
| bool | has_overridden_loop () const |
| const LogString * | get_component_log_str () const ESPHOME_ALWAYS_INLINE |
| Get the integration where this component was declared as a LogString for logging. | |
| bool | should_warn_of_blocking (uint32_t blocking_time, uint32_t &threshold_ms_out) |
Data Fields | |
| LockFreeQueue< UsbEvent, USB_EVENT_QUEUE_SIZE > | event_queue |
| EventPool< UsbEvent, USB_EVENT_QUEUE_SIZE - 1 > | event_pool |
Data Fields inherited from esphome::Component | |
| uint32_t | length = 5000) |
Protected Member Functions | |
| bool | process_usb_events_ () |
| void | handle_open_state_ () |
| TransferRequest * | get_trq_ () |
| virtual void | disconnect () |
| virtual void | on_connected () |
| virtual bool | reports_connection_itself () const |
| Whether the subclass reports the device as connected itself, once its own setup of the device has finished, rather than as soon as the device has been opened. | |
| void | report_connected_ () |
| Report the claimed device to the connection callbacks. | |
| virtual void | on_disconnected () |
| void | usb_task_loop_ () const |
Protected Member Functions inherited from esphome::Component | |
| friend | void::setup () |
| friend | void::original_setup () |
| void | set_component_source_ (uint8_t index) |
| Set where this component was loaded from for some debug messages. | |
| virtual void | call_setup () |
| void | call_dump_config_ () |
| void | enable_loop_slow_path_ () |
| void | set_component_state_ (uint8_t state) |
| Helper to set component state (clears state bits and sets new state) | |
| bool | set_status_flag_ (uint8_t flag) |
| Helper to set a status LED flag on both this component and the app. | |
| bool | set_error_flag_ (const LogString *message) |
| Set the error flag and log it; true when it was not set before. | |
| void | set_interval (const char *name, uint32_t interval, std::function< void()> &&f) |
| Set an interval function with a const char* name. | |
| void | set_interval (uint32_t id, uint32_t interval, std::function< void()> &&f) |
| Set an interval function with a numeric ID (zero heap allocation). | |
| void | set_interval (InternalSchedulerID id, uint32_t interval, std::function< void()> &&f) |
| void | set_interval (uint32_t interval, std::function< void()> &&f) |
| bool | cancel_interval (const char *name) |
| Cancel an interval function. | |
| bool | cancel_interval (uint32_t id) |
| bool | cancel_interval (InternalSchedulerID id) |
| void | set_timeout (const char *name, uint32_t timeout, std::function< void()> &&f) |
| Set a timeout function with a const char* name. | |
| void | set_timeout (uint32_t id, uint32_t timeout, std::function< void()> &&f) |
| Set a timeout function with a numeric ID (zero heap allocation). | |
| void | set_timeout (InternalSchedulerID id, uint32_t timeout, std::function< void()> &&f) |
| void | set_timeout (uint32_t timeout, std::function< void()> &&f) |
| bool | cancel_timeout (const char *name) |
| Cancel a timeout function. | |
| bool | cancel_timeout (uint32_t id) |
| bool | cancel_timeout (InternalSchedulerID id) |
| void | defer (const char *name, std::function< void()> &&f) |
| Defer a callback to the next loop() call with a const char* name. | |
| void | defer (std::function< void()> &&f) |
| Defer a callback to the next loop() call. | |
| void | defer (uint32_t id, std::function< void()> &&f) |
| Defer a callback with a numeric ID (zero heap allocation) | |
| bool | cancel_defer (const char *name) |
| Cancel a defer callback using the specified name, name must not be empty. | |
| bool | cancel_defer (uint32_t id) |
| void | status_clear_warning_slow_path_ () |
| void | status_clear_error_slow_path_ () |
Static Protected Member Functions | |
| static void | usb_task_fn (void *arg) |
Protected Attributes | |
| TransferRequest | requests_ [MAX_REQUESTS] {} |
| TaskHandle_t | usb_task_handle_ {nullptr} |
| usb_host_client_handle_t | handle_ {} |
| usb_device_handle_t | device_handle_ {} |
| int | device_addr_ {-1} |
| int | state_ {USB_CLIENT_INIT} |
| LazyCallbackManager< void(bool)> | connection_callback_ |
| std::atomic< trq_bitmask_t > | trq_in_use_ |
| const char16_t * | manufacturer_filter_ {nullptr} |
| const char16_t * | product_filter_ {nullptr} |
| uint16_t | vid_ {} |
| uint16_t | pid_ {} |
| bool | connection_reported_ {false} |
Protected Attributes inherited from esphome::Component | |
| uint8_t | component_source_index_ {0} |
| Index into component source PROGMEM lookup table (0 = not set) | |
| uint8_t | warn_if_blocking_over_ {WARN_IF_BLOCKING_OVER_CS} |
| Warn threshold in centiseconds (max 2550ms) | |
| uint8_t | component_state_ {0x00} |
| State of this component - each bit has a purpose: Bits 0-2: Component state (0x00=CONSTRUCTION, 0x01=SETUP, 0x02=LOOP, 0x03=FAILED, 0x04=LOOP_DONE) Bit 3: STATUS_LED_WARNING Bit 4: STATUS_LED_ERROR Bit 5: Has overridden loop() (set at registration time) Bits 6-7: Unused - reserved for future expansion. | |
| volatile bool | pending_enable_loop_ {false} |
| ISR-safe flag for enable_loop_soon_any_context. | |
| ComponentRuntimeStats | runtime_stats_ |
Definition at line 150 of file usb_host.h.
|
inline |
Definition at line 154 of file usb_host.h.
|
inline |
Register a callback for the device this client claims being connected (true) or removed (false).
Fires only for a device that was fully opened, so a device another client claims is never reported. Called from the main loop: connected once the device has been enumerated and the subclass has finished its setup of it (whether or not that setup succeeded), removed after on_disconnected() has run. This tracks the device's presence, not whether a given channel is usable.
Definition at line 184 of file usb_host.h.
| bool esphome::usb_host::USBClient::control_transfer | ( | uint8_t | type, |
| uint8_t | request, | ||
| uint16_t | value, | ||
| uint16_t | index, | ||
| const transfer_cb_t & | callback, | ||
| const std::vector< uint8_t > & | data = {} ) |
Definition at line 519 of file usb_host_client.cpp.
|
protectedvirtual |
Definition at line 499 of file usb_host_client.cpp.
|
overridevirtual |
Reimplemented from esphome::Component.
Reimplemented in esphome::usb_uart::USBUartComponent, and esphome::usb_uart::USBUartTypeCH34X.
Definition at line 652 of file usb_host_client.cpp.
| bool esphome::usb_host::USBClient::get_device_info | ( | UsbDeviceInfo & | info | ) | const |
Copy the connected device's identity out of the cached USB descriptors.
Returns false when no device is connected or the host stack refused the query.
Definition at line 204 of file usb_host_client.cpp.
|
inlineoverridevirtual |
Reimplemented from esphome::Component.
Definition at line 158 of file usb_host.h.
|
protected |
Definition at line 470 of file usb_host_client.cpp.
|
inline |
Definition at line 165 of file usb_host.h.
|
protected |
Definition at line 356 of file usb_host_client.cpp.
|
inline |
Whether a device has been opened and its setup by the subclass has finished.
Definition at line 172 of file usb_host.h.
|
overridevirtual |
Reimplemented from esphome::Component.
Reimplemented in esphome::usb_uart::USBUartComponent.
Definition at line 350 of file usb_host_client.cpp.
|
inlineprotectedvirtual |
Reimplemented in esphome::usb_uart::USBUartTypeCdcAcm.
Definition at line 204 of file usb_host.h.
|
inlineprotectedvirtual |
Reimplemented in esphome::usb_uart::USBUartTypeCdcAcm.
Definition at line 212 of file usb_host.h.
| void esphome::usb_host::USBClient::on_opened | ( | uint8_t | addr | ) |
Definition at line 432 of file usb_host_client.cpp.
| void esphome::usb_host::USBClient::on_removed | ( | usb_device_handle_t | handle | ) |
Definition at line 438 of file usb_host_client.cpp.
|
protected |
Definition at line 317 of file usb_host_client.cpp.
| void esphome::usb_host::USBClient::release_trq | ( | TransferRequest * | trq | ) |
Definition at line 672 of file usb_host_client.cpp.
|
protected |
Report the claimed device to the connection callbacks.
Idempotent; a subclass that reports itself calls this once the device is ready to use.
Definition at line 424 of file usb_host_client.cpp.
|
inlineprotectedvirtual |
Whether the subclass reports the device as connected itself, once its own setup of the device has finished, rather than as soon as the device has been opened.
Reimplemented in esphome::usb_uart::USBUartComponent.
Definition at line 208 of file usb_host.h.
|
inline |
Definition at line 168 of file usb_host.h.
|
inline |
Definition at line 169 of file usb_host.h.
|
overridevirtual |
Reimplemented from esphome::Component.
Reimplemented in esphome::usb_uart::USBUartComponent.
Definition at line 276 of file usb_host_client.cpp.
| bool esphome::usb_host::USBClient::transfer_in | ( | uint8_t | ep_address, |
| const transfer_cb_t & | callback, | ||
| uint16_t | length ) |
Performs a transfer input operation.
THREAD CONTEXT: Called from both USB task and main loop threads!
| ep_address | The endpoint address. |
| callback | The callback function to be called when the transfer is complete. |
| length | The length of the data to be transferred. |
| None. |
Definition at line 587 of file usb_host_client.cpp.
| bool esphome::usb_host::USBClient::transfer_out | ( | uint8_t | ep_address, |
| const transfer_cb_t & | callback, | ||
| const uint8_t * | data, | ||
| uint16_t | length ) |
Performs an output transfer operation.
THREAD CONTEXT: Called from both USB task and main loop threads.
| ep_address | The endpoint address. |
| callback | The callback function to be called when the transfer is complete. |
| data | The data to be transferred. |
| length | The length of the data to be transferred. |
| None. |
Definition at line 628 of file usb_host_client.cpp.
|
staticprotected |
Definition at line 307 of file usb_host_client.cpp.
|
protected |
Definition at line 311 of file usb_host_client.cpp.
|
protected |
Definition at line 228 of file usb_host.h.
|
protected |
Definition at line 239 of file usb_host.h.
|
protected |
Definition at line 226 of file usb_host.h.
|
protected |
Definition at line 225 of file usb_host.h.
Definition at line 194 of file usb_host.h.
| LockFreeQueue<UsbEvent, USB_EVENT_QUEUE_SIZE> esphome::usb_host::USBClient::event_queue |
Definition at line 190 of file usb_host.h.
|
protected |
Definition at line 224 of file usb_host.h.
|
protected |
Definition at line 233 of file usb_host.h.
|
protected |
Definition at line 236 of file usb_host.h.
|
protected |
Definition at line 234 of file usb_host.h.
|
protected |
Definition at line 222 of file usb_host.h.
|
protected |
Definition at line 227 of file usb_host.h.
|
protected |
Definition at line 232 of file usb_host.h.
|
protected |
Definition at line 223 of file usb_host.h.
|
protected |
Definition at line 235 of file usb_host.h.
